Technical Description

SOLAR MODULE EL/AOI MACHINE

High  resolution ：EL camera 2.3M pixels *12; AOI camera 12M pixels *12, eight cameras in total

Automatically photoshooting and photo stitching

NG modules can be automatically recognized through AI calculation after capturing EL or exterior image

Fast change over between modules of different specifications within 5 minutes

Technical Parameters

Model-EL&FAOI-MIS-2

working cycle time-19s（transOmission ion speed: 60cm/s, continuous mode）

Image capture time-Exposure + capture ≤1.5s；(line scan capture 3 times)

Testing mode-High current (1lsc),low current (0.1lsc）,automatic switching between high and low currents

Display screen-55-inch high-resolution 4K television *2

Dimension（L*W*H）-2400*3200*2100mm

Module type-Mono/Poly conventional/double-glass module

Module dimension-2500*1500mm

Image capture direction-Anode side facing downwards

Operation Power-AC 220V，50HZ

Rated Power-2.5kW

Operation Air Pressure-0.5~0.8Mpa

Air consumption-1.6L/min

Environment temperature-20~30℃

Omission detection rate-≤0.03%

False detection rate-≤1%
