Technical Description

SOLAR CELL SHINGLING MACHINE

Maximum capacity: 3200UPH for full cell

Multi-lanes, with several high-precision 4-Axis robots,  high speed shingling process

Self-developed imaging system can effectively reduce the defect rate,  repair rate and scrap rate

Whole line for printing function shingle , high precision shingling

Auto unloading and string flipper, open connection to Autoline/Layup

Compatible with 1/4、1/5、1/6 cell

Technical Parameters

Resolution of alignment system-≤0.1 mm

Accuracy of shingling-±0.15mm

Width of Overlapping area -1.0-3.0mm

Alignment mode -Contour detection

String length-360-2200mm

String length error-±0.5mm

Temperature range of heating plate-Form room temp to 200 ℃

Temperature uniformity of heating plate surface -±10℃

Curing temperature and duration-≤170 degree,   Max.15 seconds

Buffer for small cell w/o glue -Standard

Mono cell with angle of chamfer-Available

Solar cell rotation less than 180° -Available
