Technical Description

8.EVA/TPT AUTOMATIC CUTTING MACHINE

Great compatibility, compatible with materials with maximum diameter up to 800mm

Simple and convenient uploading with auxiliary unit of cutting loading.

Equipped with an electrostatic eliminator to effectively remove the static

With the function of melting bonding EVA function to improve the efficiency and convenience of operation

With the function of TPT head detection to effectively avoid material waste

Equipped with punch module which is adjustable and adaptable

The whole machine is with protecting cover plate, and uploading side is protected by light fence, beautiful and safe.

Technical Parameters

Operation Power-AC 380V 3-phase 5-wire system of 50Hz/60Hz

Operation Air Pressure-0.6-0.8Mpa

Compatible material size-Length: 1650-2500 mm*Width:990-1400mm

Compatible maximum material specification-Diameter 800mm

Operating Noise-＜72db

Cutting accuracy-EVA±2mm；TPT±1.5mm

Laying accuracy-±1.5mm

Rated Power-8kW

Air consumption-100L/min

working cycle time-20s

Equipment Dimension（L*W*H）-5940x2250x1700mm

Maximum weight of single unit-1400kg
